  1. All Xbox 360 Schematics

    Автор Fenix

    Схемы всех игровых приставок XBOX 360
    Schematics:
    XBOX 360 Corona
    Xbox_360_Falcon
    Xbox_360_Jasper
    XBOX_360_Trinity
    Xbox_360_Zephyr_A

    0 раз скачали

    Обновлено

  2. Datasheet - BD9B301MUV-LB 2.7V to 5.5V Input, 3.0A Integrated MOSFET

    Автор Fenix

    This is the product guarantees long time support in Industrial market.
    BD9B301MUV-LB is a synchronous buck switching regulator with built-in low on-resistance power MOSFETs.
    This IC, which is capable of providing current up to 3A, features fast transient response by employing constant on-time control system. It offers high oscillating
    frequency at low inductance. With its original constant on-time control method which operates low consumption at light load, this product is ideal for equipment and devices that demand minimal standby power consumption.

    0 раз скачали

    Отправлено

  3. Datasheet STDP8028 – Single-chip enhanced monitor controller

    Автор Fenix

    Features
    ■ Dual 10-bit triple ADCs with capture up to 205 MHz
    ■ Integrated dual digital inputs supporting HDMI 1.3 receiver
    ■ Integrated DisplayPort 1.1 compliant receiver
    ■ Integrated 3D video decoder
    ■ Next generation true 10-bit Faroudja DCDi Cinema® format processing
    ■ Flexible DDR2 memory interface 32 bits wide
    ■ Advanced Picture-in-Picture (PIP) features capabilities
    ■ Faroudja RealColor® processing

    0 раз скачали

    Отправлено

  4. Datasheet NCP1602 Enhanced, High-Efficiency Power Factor Controller

    Автор Fenix

    The 6−pin PFC controller NCP1602 is designed to drive PFC boost
    stages. It is based on an innovative Valley Synchronized Frequency
    Fold−back (VSFF) method. In this mode, the circuit classically
    operates in Critical conduction Mode (CrM) when Vcontrol voltage
    exceeds a programmable value Vctrl,FF. When Vcontrol is below this
    preset level Vctrl,FF, the NCP1602 (versions [B**] and [D**]) linearly
    decays the frequency down to about 30 kHz until Vcontrol reaches the
    SKIP mode threshold. VSFF maximizes the efficiency at both
    nominal and light load. In particular, the stand−by losses are reduced
    to a minimum. Like in FCCrM controllers, internal circuitry allows
    near−unity power factor even when the switching frequency is
    reduced. Housed in a TSOP6 package, the circuit also incorporates the
    features necessary for robust and compact PFC stages, with few
    external components.

    0 раз скачали

    Отправлено

  5. Datasheet MP3398E – 4-STRING, 80V, STEP-UP, WLED CONTROLLER

    Автор Fenix

    The MP3398E is a step-up controller with four
    current channels designed to drive WLED
    arrays for large LCD panel backlighting
    applications. The MP3398E is able to expand
    the number of LED channels with two or more
    ICs in parallel sharing a single power source.

    0 раз скачали

    Обновлено

  6. Datasheet AOZ3015PI - 3 A Synchronous Buck Regulator

    Автор Fenix

    EZBuck™ 3 A Synchronous Buck Regulator
    The AOZ3015PI is a high efficiency, easy to use, 3 A
    synchronous buck regulator. The AOZ3015PI works from
    4.5 V to 18 V input voltage range, and provides up to 3 A
    of continuous output current with an output voltage
    adjustable down to 0.8 V.

    1 раз скачали

    Обновлено

×
×
